Appendix C: Master Constraints File Listing
set_property PACKAGE_PIN AH29 [get_ports FMC1_LA33_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_LA33_P]
set_property PACKAGE_PIN AH30 [get_ports FMC1_LA33_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_LA33_N]
#FMC1 HA
set_property PACKAGE_PIN AV40 [get_ports FMC1_HA00_CC_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA00_CC_P]
set_property PACKAGE_PIN AW40 [get_ports FMC1_HA00_CC_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA00_CC_N]
set_property PACKAGE_PIN AY39 [get_ports FMC1_HA01_CC_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA01_CC_P]
set_property PACKAGE_PIN AY40 [get_ports FMC1_HA01_CC_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA01_CC_N]
set_property PACKAGE_PIN AT41 [get_ports FMC1_HA02_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA02_P]
set_property PACKAGE_PIN AU42 [get_ports FMC1_HA02_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA02_N]
set_property PACKAGE_PIN AY42 [get_ports FMC1_HA03_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA03_P]
set_property PACKAGE_PIN BA42 [get_ports FMC1_HA03_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA03_N]
set_property PACKAGE_PIN AU41 [get_ports FMC1_HA04_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA04_P]
set_property PACKAGE_PIN AV41 [get_ports FMC1_HA04_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA04_N]
set_property PACKAGE_PIN BA41 [get_ports FMC1_HA05_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA05_P]
set_property PACKAGE_PIN BB41 [get_ports FMC1_HA05_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA05_N]
set_property PACKAGE_PIN AW41 [get_ports FMC1_HA06_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA06_P]
set_property PACKAGE_PIN AW42 [get_ports FMC1_HA06_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA06_N]
set_property PACKAGE_PIN AJ30 [get_ports FMC1_HA07_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA07_P]
set_property PACKAGE_PIN AK30 [get_ports FMC1_HA07_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA07_N]
set_property PACKAGE_PIN AF29 [get_ports FMC1_HA08_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA08_P]
set_property PACKAGE_PIN AG29 [get_ports FMC1_HA08_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA08_N]
set_property PACKAGE_PIN AK28 [get_ports FMC1_HA09_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA09_P]
set_property PACKAGE_PIN AK29 [get_ports FMC1_HA09_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA09_N]
set_property PACKAGE_PIN AF30 [get_ports FMC1_HA10_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA10_P]
set_property PACKAGE_PIN AG31 [get_ports FMC1_HA10_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA10_N]
set_property PACKAGE_PIN AH28 [get_ports FMC1_HA11_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA11_P]
set_property PACKAGE_PIN AJ28 [get_ports FMC1_HA11_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA11_N]
set_property PACKAGE_PIN AC31 [get_ports FMC1_HA12_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA12_P]
set_property PACKAGE_PIN AD31 [get_ports FMC1_HA12_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA12_N]
set_property PACKAGE_PIN AA31 [get_ports FMC1_HA13_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA13_P]
