Xilinx Virtex-7 VC7203 User Manual

VC7203 GTX Transceiver Characterization Board www.xilinx.com 55
UG957 (v1.3) October 17, 2014
VC7203 Board XDC Listing
set_property PACKAGE_PIN AA32 [get_ports FMC1_HA13_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA13_N]
set_property PACKAGE_PIN AC30 [get_ports FMC1_HA14_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA14_P]
set_property PACKAGE_PIN AD30 [get_ports FMC1_HA14_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA14_N]
set_property PACKAGE_PIN AA29 [get_ports FMC1_HA15_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA15_P]
set_property PACKAGE_PIN AA30 [get_ports FMC1_HA15_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA15_N]
set_property PACKAGE_PIN AB29 [get_ports FMC1_HA16_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA16_P]
set_property PACKAGE_PIN AC29 [get_ports FMC1_HA16_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HA16_N]
#FMC1 HB
set_property PACKAGE_PIN AB33 [get_ports FMC1_HB00_CC_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HB00_CC_P]
set_property PACKAGE_PIN AC33 [get_ports FMC1_HB00_CC_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HB00_CC_N]
set_property PACKAGE_PIN AF35 [get_ports FMC1_HB01_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HB01_P]
set_property PACKAGE_PIN AF36 [get_ports FMC1_HB01_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HB01_N]
set_property PACKAGE_PIN AE37 [get_ports FMC1_HB02_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HB02_P]
set_property PACKAGE_PIN AF37 [get_ports FMC1_HB02_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HB02_N]
set_property PACKAGE_PIN AF34 [get_ports FMC1_HB03_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HB03_P]
set_property PACKAGE_PIN AG34 [get_ports FMC1_HB03_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HB03_N]
set_property PACKAGE_PIN AD36 [get_ports FMC1_HB04_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HB04_P]
set_property PACKAGE_PIN AD37 [get_ports FMC1_HB04_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HB04_N]
set_property PACKAGE_PIN AC35 [get_ports FMC1_HB05_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HB05_P]
set_property PACKAGE_PIN AC36 [get_ports FMC1_HB05_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HB05_N]
set_property PACKAGE_PIN AB31 [get_ports FMC1_HB06_CC_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HB06_CC_P]
set_property PACKAGE_PIN AB32 [get_ports FMC1_HB06_CC_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HB06_CC_N]
set_property PACKAGE_PIN AG36 [get_ports FMC1_HB07_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HB07_P]
set_property PACKAGE_PIN AH36 [get_ports FMC1_HB07_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HB07_N]
set_property PACKAGE_PIN Y37 [get_ports FMC1_HB08_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HB08_P]
set_property PACKAGE_PIN AA37 [get_ports FMC1_HB08_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HB08_N]
set_property PACKAGE_PIN Y35 [get_ports FMC1_HB09_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HB09_P]
set_property PACKAGE_PIN AA36 [get_ports FMC1_HB09_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HB09_N]
set_property PACKAGE_PIN AB36 [get_ports FMC1_HB10_P]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HB10_P]
set_property PACKAGE_PIN AB37 [get_ports FMC1_HB10_N]
set_property IOSTANDARD LVCMOS18 [get_ports FMC1_HB10_N]
Send Feedback

Xilinx Virtex-7 VC7203 Specifications

General

FPGA Family	Virtex-7
Transceiver	GTH
GTH Transceivers	16
Maximum Data Rate	13.1 Gbps
Transceivers	16
Maximum Transceiver Speed	13.1 Gbps
Maximum User I/O	600
Process Technology	28nm
Block RAM	38 Mb
Power Supply Voltage	0.9V
Operating Temperature Range	Industrial
