ZCU102 Evaluation Board User Guide www.xilinx.com 6
UG1182 (v1.2) March 20, 2017
Chapter 1
Introduction
Overview
The ZCU102 is a general purpose evaluation board for rapid-prototyping based on the
Zynq® UltraScale+
™
XCZU9EG-2FFVB1156I MPSoC (multiprocessor system-on-chip). High
speed DDR4 SODIMM and component memory interfaces, FMC expansion ports,
multi-gigabit per second serial transceivers, a variety of peripheral interfaces, and FPGA
logic for user customized designs provides a flexible prototyping platform.
Send Feedback

Xilinx ZCU102 Specifications

General

Processor	Quad-core ARM Cortex-A53, Dual-core ARM Cortex-R5
SD Card	MicroSD card slot
Video Outputs	DisplayPort
FPGA	Xilinx Zynq UltraScale+ XCZU9EG-2FFVB1156E
Memory	4GB DDR4 Component Memory
Storage	MicroSD card slot
Ethernet	Gigabit Ethernet
USB	1 x USB 3.0, 1 x USB 2.0
PCIe	PCIe Gen2 x4
Display	DisplayPort
Power Supply	12V DC input
SATA	SATA 3.0
Clocking	Programmable clocks
Operating System Support	PetaLinux
