ZCU102 Evaluation Board User Guide www.xilinx.com 20
UG1182 (v1.2) March 20, 2017
Chapter 3
Board Component Descriptions
Overview
This chapter provides a detailed functional description of the board’s components and
features. Table 2-1, page 13 identifies the components, references the respective schematic
page numbers, and links to the corresponding detailed functional description in this
chapter. Component locations are shown in Figure 2-1, page 12.
Component Descriptions
Zynq UltraScale XCZU9EG MPSoC
[Figure 2-1, callout 1]
The ZCU102 board is populated with the Zynq UltraScale+ XCZU9EG-2FFVB1156I MPSoC
which combines a powerful processing system (PS) and user-programmable logic (PL) into
the same device. The processing system in a Zynq UltraScale+ MPSoC features the ARM®
flagship Cortex®-A53 64-bit quad-core processor and Cortex-R5 dual-core real-time
processor.
Production ZCU102 Evaluation boards will ship with -2LE speed grade devices. Support of
multiple speed grades requires voltage adjustments.
The PL-side V
CCINT
supply will be user adjustable via PMBUS with the voltage ranges shown
in Table 3-1 to support multiple Zynq UltraScale+ MPSoC speed grades.
Table 3-1: Recommended Operating Conditions
Symbol Description Min. Typ. Max Units
Programmable Logic (PL)
V
CCINT
Internal supply voltage.
0.825 0.850 0.875 V
For -1LI and -2LE devices: internal supply voltage.
0.698 0.720 0.742 V
For -3E devices: internal supply voltage.
0.873 0.900 0.927 V
