Chapter 3: Board Component Descriptions
SD1 (MIO 39-51)
A PS-side interface to an SD card connector is provided for booting and file system storage.
This interface is used for the SD boot mode and supports SD3.0 access post boot.
SD Card Interface
[Figure 2-1, callout 6]
The ZCU102 board includes a secure digital input/output (SDIO) interface to provide access
to general purpose non-volatile SDIO memory cards and peripherals. Information for the
SD I/O card specification can be found at the SanDisk Corporation [Ref 15] or SD
Association [Ref 16] websites. The ZCU102 SD card interface supports the SD1_LS
configuration boot mode documented in the Zynq UltraScale+ MPSoC Technical Reference
Manual (UG1085) [Ref 2].
The SDIO signals are connected to XCZU9EG MPSoC PS bank 501 which has its V
CCMIO
set
to 1.8V. Each of the six MIOxx_SDIO_* nets has a series 30 ohm resistor at the source. An
NXP IP4856CX25 SD 3.0-compliant voltage level-translator U133 is present between the
XCZU9EG MPSoC and the SD card connector (J100). The NXP IP4856CX25 U133 device
provides SD3.0 capability with SDR104 performance. The NXP SD3.0 level shifter is mounted
on an Aries adapter board that has the pin mapping shown in Table 3-9.
Table 3-9: U133 IP4856CX25 Adapter Pin-Out
Aires Adapter
Pin Number
IP4856CX25 U133
Pin Number
IP4856CX25 U133
Pin Name
1C1
CLK_IN
2C3
GND
3D3
CD
4D2
CMD_H
5E2
CLK_FB
6E4
WP
7B4
VLDO
8C4
V
SD_REF
9A3
DIR_0
10 A4
V
SUPPLY
11 B3
V
CCA
12 A2
DIR_CMD
13 D1
DATA0_H
14 B2
SEL
15 B1
DATA3_H
16 E1
DATA1_H
