Chapter 3: Board Component Descriptions
Figure 3-5 shows the connections of the SD card interface on the ZCU102 board.
Table 3-10 lists the SD card interface connections to the XCZU9EG MPSoC.
17 E3
DIR_1_3
18 A1
DATA2_H
19 E5
DATA1_SD
20 D5
DATA0_SD
21 C5
CLK_SD
22 D4
CMD_SD
23 B5
DATA3_SD
24 A5
DATA2_SD
25 C2
ENABLE
Table 3-9: U133 IP4856CX25 Adapter Pin-Out (Cont’d)
Aires Adapter
Pin Number
IP4856CX25 U133
Pin Number
IP4856CX25 U133
Pin Name
X-Ref Target - Figure 3-5
Figure 3-5: SD Card Interface
;
Table 3-10: SD Interface Connections to the XCZU9EG MPSoC
XCZU9EG (U1)
Pin
Net Name
U133 IP4856CX25 Adapter
Pin Number Pin Name
N23
MIO39_SDIO_SEL
14
SEL
M23
MIO40_SDIO_DIR_CMD
12
DIR_CMD
