Chapter 1: Introduction
Board Features
The ZCU102 evaluation board features are listed here. Detailed information for each feature
is provided in Chapter 3, Board Component Descriptions.
• XCZU9EG-2FFVB1156I MPSoC
•PL V
CCINT
for range in datasheet
• Form factor for PCIe Gen2x4 Host, Micro-ATX chassis footprint
• Configuration from QSPI
• Configuration from SD card
• Configuration over JTAG with PC4 header
• Configuration over JTAG with ARM 20-pin header
• Configuration over USB-to-JTAG Bridge
• Clocks (PL-system, PS_CLK, Programmable Clock, SMA, SMA_GT_REF, Ethernet, USB)
• PS DDR4 64-bit SODIMM w/ ECC
• PL DDR4 Component (16-bit)
• PS GTR assignment
°
SATA
°
DisplayPort
°
USB3
°
PCIe Gen2x4 Root Port
• PL GTH assignment
°
FMC #1 (8 GTH) and FMC #2 (8 GTH) PL GT assignment
°
HDMI (3 GTH) PL GT assignment
°
SFP+ (4 GTH) PL GT assignment
°
SMA (1 GTH) PL GT assignment
• PL FMC HPC #1 Connectivity - Full LA Bus
• PL FMC HPC #2 Connectivity - Partial LA Bus
•PS MIO: QSPI
• PS MIO: Ethernet
• PS MIO: USB2 (same connector as USB3)
• PS MIO: SD
Send Feedback

Xilinx ZCU102 Specifications

General

Processor	Quad-core ARM Cortex-A53, Dual-core ARM Cortex-R5
SD Card	MicroSD card slot
Video Outputs	DisplayPort
FPGA	Xilinx Zynq UltraScale+ XCZU9EG-2FFVB1156E
Memory	4GB DDR4 Component Memory
Storage	MicroSD card slot
Ethernet	Gigabit Ethernet
USB	1 x USB 3.0, 1 x USB 2.0
PCIe	PCIe Gen2 x4
Display	DisplayPort
Power Supply	12V DC input
SATA	SATA 3.0
Clocking	Programmable clocks
Operating System Support	PetaLinux
