ZCU102 Evaluation Board User Guide www.xilinx.com 9
UG1182 (v1.2) March 20, 2017
Chapter 1: Introduction
•PS MIO: CAN
• PS MIO: UART (using USB-to-UART bridge)
• PS MIO: Second UART
• PS MIO: I2C shared across PS and PL
•PS/PL EMIO: Trace
•PL-side UART
• PL-side LEDs (8)
• PL-side DIP switch (8-position)
• PL-side Pushbuttons (5)
• PS-side Pushbutton (1)
• PS-side LED (1)
• System User Switches (PROG, CPU Reset)
•PJTAG
• Security - PSBATT button battery backup
•SYSMON
• Operational Switches (Power on/off, PROG, Boot mode)
• Operational Status LEDs (power supply status, INIT, DONE, PG, JTAG status, DDR power
good)
• Power Management
The ZCU102 evaluation board provides designers a rapid prototyping platform utilizing the
XCZU9EG-2FFVB1156I device. The ZU9EG contains many useful processor system (PS) hard
block peripherals exposed through the Multi-use I/O (MIO) interface and a variety of FPGA
programmable logic (PL), high-density (HD) and high-performance (HP) banks. Table 1-1
lists a brief summary of the resources available within the ZU9EG. A feature set overview,
description, and ordering information is provided in the UltraScale Architecture and Product
Overview (DS890) [Ref 1].
Table 1-1: Zynq UltraScale+ MPSoC ZCU9EG Features and Resources
Feature Resource Count
HD banks 5 banks, total of 120 pins
HP banks 4 banks, total of 208 pins
MIO banks 3 banks, total of 78 pins
PS-side GTR 6 Gb/s transceivers 4 PS-GTRs
PL-side GTH 16.3 Gb/s transceivers 24 GTHs
Effective LEs 575K
