ZCU102 Evaluation Board User Guide www.xilinx.com 48
UG1182 (v1.2) March 20, 2017
Chapter 3: Board Component Descriptions
GEM3 Ethernet (MIO 64-77)
[Figure 2-1, callout 12]
The PS-side Gigabit Ethernet MAC (GEM) implements a 10/100/1000 Mb/s Ethernet
interface, shown in Figure 3-12, which connects to a TI DP83867IRPAP Ethernet RGMII PHY
before being routed to an RJ45 Ethernet connector. The RGMII Ethernet PHY is boot
strapped to PHY address 5'b01100 (0x0C) and Auto Negotiation set to Enable.
Communication with the device is covered in the DP83867 RGMII PHY data sheet [Ref 18].
X-Ref Target - Figure 3-12
Figure 3-12: Ethernet Block Diagram
7,
'3,5
*(0
0,2
5*0,,
0',2
5-DQG
0DJQHWLFV
;
Send Feedback

Xilinx ZCU102 Specifications

General

Processor	Quad-core ARM Cortex-A53, Dual-core ARM Cortex-R5
SD Card	MicroSD card slot
Video Outputs	DisplayPort
FPGA	Xilinx Zynq UltraScale+ XCZU9EG-2FFVB1156E
Memory	4GB DDR4 Component Memory
Storage	MicroSD card slot
Ethernet	Gigabit Ethernet
USB	1 x USB 3.0, 1 x USB 2.0
PCIe	PCIe Gen2 x4
Display	DisplayPort
Power Supply	12V DC input
SATA	SATA 3.0
Clocking	Programmable clocks
Operating System Support	PetaLinux
