Xilinx ZCU102 User Manual

ZCU102 Evaluation Board User Guide www.xilinx.com 79
UG1182 (v1.2) March 20, 2017
Chapter 3: Board Component Descriptions
Figure 3-34 shows the power and status LEDs.
GTH Transceivers
[Figure 2-1, callout 1]
The Zynq UltraScale+ MPSoC has 24 GTH gigabit transceivers (16.3 Gb/s capable) on the
PL-side.
The GTH transceivers in the XCZU9EG device are grouped into four channels referred to as
Quads. The reference clock for a Quad can be sourced from the Quad above or Quad below
the GTH Quad of interest. There are six GTH Quads on the ZCU102 board with connectivity
as shown here:
• Two of the GTH transceivers are wired to the FMC0 HPC connector (J5)
• Two of the GTH transceivers are wired to the FMC1 HPC connector (J4)
X-Ref Target - Figure 3-34
Figure 3-34: Power and Status LEDs
;
Send Feedback

Xilinx ZCU102 Specifications

General

Processor	Quad-core ARM Cortex-A53, Dual-core ARM Cortex-R5
SD Card	MicroSD card slot
Video Outputs	DisplayPort
FPGA	Xilinx Zynq UltraScale+ XCZU9EG-2FFVB1156E
Memory	4GB DDR4 Component Memory
Storage	MicroSD card slot
Ethernet	Gigabit Ethernet
USB	1 x USB 3.0, 1 x USB 2.0
PCIe	PCIe Gen2 x4
Display	DisplayPort
Power Supply	12V DC input
SATA	SATA 3.0
Clocking	Programmable clocks
Operating System Support	PetaLinux
