Xilinx ZCU102 User Manual

ZCU102 Evaluation Board User Guide www.xilinx.com 10
UG1182 (v1.2) March 20, 2017
Chapter 1: Introduction
Board Specifications
Dimensions
Width: 9.350 in. (23.749 cm)
Length: 9.600 in. (24.384 cm)
Thickness: 0.104 in. (0.2642 cm)
Notes:
• A 3D model of this board is not available.
• ZCU102 board documentation (xdc listing, schematics, layout files and board outline/fab
drawings, etc.) is available on the web at: www.xilinx.com/zcu102
.
Environmental
Temperature
Operating: 0°C to +45°C
Storage: -25°C to +60°C
Humidity
10% to 90% non-condensing
Operating Voltage
+12 V
DC
Logic cells 480K
CLB flip-flops 548K
Max. distributed RAM 8.8 Mb
Total block RAM 32.1 Mb
DSP slices 2,520
Table 1-1: Zynq UltraScale+ MPSoC ZCU9EG Features and Resources (Cont’d)
Feature Resource Count
Send Feedback

Xilinx ZCU102 Specifications

General

Processor	Quad-core ARM Cortex-A53, Dual-core ARM Cortex-R5
SD Card	MicroSD card slot
Video Outputs	DisplayPort
FPGA	Xilinx Zynq UltraScale+ XCZU9EG-2FFVB1156E
Memory	4GB DDR4 Component Memory
Storage	MicroSD card slot
Ethernet	Gigabit Ethernet
USB	1 x USB 3.0, 1 x USB 2.0
PCIe	PCIe Gen2 x4
Display	DisplayPort
Power Supply	12V DC input
SATA	SATA 3.0
Clocking	Programmable clocks
Operating System Support	PetaLinux
