Xinje VH5 Series User Manual

14
Index
Sub-index
Name
Data type
Access
06
Calc and copy Time
UINT32
RO
08
Get cycle time
UINT16
RW
09
Delay time
UINT32
RO
10
Sync0 cycle time
UINT32
RW
11
SM-Event Missed
UINT16
RO
12
Cycle time too small
UINT16
RO
32
Sync error
UINT8
RO
Note: Items marked with "-" in the table indicate that there are no related attributes in the object dictionary.
6.3 VFD Internal parameter mapping area (manufacturer defined area)
The object dictionary in the user-defined area of the manufacturer corresponds to the panel parameters of VFD
one by one. Only Group U parameters of the object dictionary in this area can be TPDO mapped and can be read
by PDO. Other object dictionaries can only be operated based on SDO.
Index
Sub-index
Parameter
Index
Sub-index
Parameter
2000h
00
P0-00
2900h
00
P9-00
2001h
00
P0-01
2901h
00
P9-01
2002h
00
P0-02
0902h
00
P9-02
2003h
00
P0-03
2903h
00
P9-03
...
...
...
...
...
...
201Ah
00
P0-26
291Eh
00
P9-30
2100h
00
P1-00
2A00h
00
PA-00
2101h
00
P1-01
2A01h
00
PA-01
2102h
00
P1-02
2A02h
00
PA-02
2103h
00
P1-03
2A03h
00
PA-03
...
...
...
...
...
...
2123h
00
P1-35
2A1Dh
00
PA-29
2200h
00
P2-00
2B00h
00
PB-00
2201h
00
P2-01
2B01h
00
PB-01
2202h
00
P2-02
2B02h
00
PB-02
2203h
00
P2-03
2B03h
00
PB-03
...
...
...
...
...
...
2246h
00
P2-70
2B33h
00
PB-51
2300h
00
P3-00
2C00h
00
PC-00
2301h
00
P3-01
2C01h
00
PC-01
2302h
00
P3-02
2C02h
00
PC-02
2303h
00
P3-03
2C03h
00
PC-03
...
...
...
...
...
...
2317
00
P3-23
2C46
00
PC-70
2400
00
P4-00
2F00h
00
PF -00
2401
00
P4-01
2F01h
00
PF -01
2402
00
P4-02
2F02h
00
PF -02
2403h
00
P4-03
2F03h
00
PF -03
