Xinje VH5 Series User Manual

64
10.6 KEYENCE PLC KV 7300 and VH5/VH6
10.6.1 System configuration
Name
Model
Quantity
Explanation
Upper computer
KV STUDIO Ver.9G
1
Omron upper computer software
Controller
KV_7300 series
1
-
Communication
card
VHX-CC100(V2.0)
1
-
Network cable
JC-CB-3
some
For connection between PLC and slave
USB cable
USB cable
-
For connection between computer and
PLC
10.6.2 Parameter setting
The frequency converter slave station needs to be configured as EtherCAT communication mode, and the
parameters to be modified are as follows:
Parameter
Name
Access
Set value
Range
Explanation
P0-02
Operation
command
channel
selection
Runtime
read only
2
0-2
Communication
P0-03
Main frequency
A input channel
selection
Runtime
read only
6
0-9
Communication setting
P9-00
Communication
protocol
Runtime
read only
1
0-2
EtherCAT
P9-12
Slave station
No.
RW
-
0-65535
After modification, it is
valid when power on again.
10.6.3 Setup steps
1)New project
①The computer and PLC are connected and communicated through USB port.
②Open the software and create a new project.
