Xinje VH5 Series User Manual

5
1. Product confirmation
Thank you for using XINJE VH5 / VH6 series frequency converter and selecting EtherCAT expansion card.
Please confirm the following when receiving the product:
 Check whether the Ethercat expansion card is damaged.

Confirm whether the received card is correct through the label on the board, refer to Fig1.
 Confirm whether the package is complete. Refer to Table 1.

If the card is damaged, the model is wrong, or there are omissions in the package, please contact the supplier
or salesman immediately.

Please download the XML file of this card on the website:www.xinje.com, file name: VHX-CC100.xml.
Fig. 1 Nameplate label location
Table 1 Package
Model
Content
Quantity
VH5-CC100
Communication
card
1
Screw and
bracket
1
VH6-CC100
Communication
card
1
