Xinje VH5 Series User Manual

24
 This object sets the acceleration time.
 Read / write delta time will be associated with VFD parameter P0-18.
6049hex
vl velocity deceleration
Sub-index 0:Number of entries
Range :-
Unit:-
Default value: 02hex
Size:1 byte(U8)
Access: RO
PDO map: Not possible
Sub-index 1: the maximum output frequency P0-13
Range :0 – FFFFFFFF hex
Unit: 0.01Hz
Default value: 00001388hex
Size:4 byte(U32)
Access: RO
PDO map: Not possible
Sub-index 2: Delta time
Range :0 – FFFF hex
Unit: 0.1s
Default value: 00000200hex
Size:2 byte(U16)
Access: RW
PDO map: Not possible
 This object sets the deceleration time.
 Read / write delta time will be associated with VFD parameter P0-18.
605Bhex
Shutdown option code
Range :1
Unit:-
Default value: 1
Size:2byte(INT16)
Access: RW
PDO map: Not possible
 This object describes the action during shutdown (operation enable → ready to switch on). When this
object is set to 1, it indicates deceleration shutdown, otherwise it will free shutdown.
605Chex
Disable operation option code
Range :1
Unit:-
Default value: 1
Size:2byte(INT16)
Access: RW
PDO map: Not possible

This object describes the action of canceling operation (operation enable → switch on). When this
object is set to 1, it indicates deceleration shutdown, otherwise it will free shutdown.
605Ehex
Fault reaction option code
Range :1
Unit:-
Default value: 1
Size:2byte(INT16)
Access: RW
PDO map: Not possible
 This object describes the action when an error occurs (operation enable → fault reaction active). When
this object is set to 1, it means deceleration and shutdown, otherwise free shutdown (this function is
reserved for standby).
6060hex
Mode of operation
Range :2
Unit::-
Default value: 02 hex
Size:1 byte(INT8)
Access: RW
PDO map: Not possible
6061hex
Mode of operation display
Range : 0 - 10
Unit:-
Default value: 02 hex
Size:1 byte(INT8)
Access: RO
PDO map: Not possible
 This object displays the current operation mode, which is equal to 6060 hex (mode of operation) during
operation.
6064hex
Position actual value
Range :-2147483648 - 2147483647
Unit:-
Default value: 00000002 hex
Size:4 byte(U32)
Access: RO
PDO map: Not possible

This object displays the encoder position fed back by the frequency converter.
