2-1SystemOverview
2-1-1MainPage
Note: theactualpagemaybedifferentfromthelegend.
l TheshippositionInfo.window
ItprovidesthereceivingGPSsignalinformationofownship.WhenGPSpositionssuccessfully,
ship’sLon&Latwillbedisplayedinwhiteandifpositioningfails,thedatawillbedisplayedin
darkred.
l CursorInfo.window
Itprovideslocationinformationofthecursor.Thedatawillbechangedaccordingtothecursor’s
location.
Note: Whenyouusedistancemeasurementfunction,thedatadisplayedinthecursorinfo
windowindicatesthedistanceanddirectionbetweenthetwopoints.
l Calendarwindow
l Satellitesignalwindow
Eachyellowpillarindicatesonesatellite;pinkfillerindicatesstrengthvalueofthesatellitesignal
Strengthof
satellitesignal
CursorInfo.
Thecurrenttime,quantityofsatelliteswhichsignals
arereceived,theGregorianandlunarcalendardate
Thequantityofsatelliteswhichsignals
arecurrentlyreceived.
Numberofsatellite
Strengthofsignal
Chartdirection.Itdefaultsnorthandwill
changeaccordinglywithchartrotation.
ShippositionInfo.
Calendar
