XP0100 Enterprise IP Phone Using the Advanced Phone Functions
Xorcom Ltd. 37 www.xorcom.com
5) If you select Router, enter the IP address, subnet mask in the proper fields,
enable/disable DHCP server.
6) Press to save the change or to cancel.
To configure PC Port via web user interface:
Click on Network->Basic-> LAN to do the relating configuration. Contact your
system administrator for more information.
VLAN Setting
VLAN is a group of hosts with a common set of requirements that communicate as if
they were attached to the Broadcast domain, regardless of their physical location. The
following table lists the instruction of the field about the VLAN Setting.
When the network capacity is insufficient, QoS could provide
priority to users by setting the value.
To configure VLAN settings via phone user interface:
1) Press ->Settings->Advanced.
2) Enter the password required, scroll to Network option, and then press .
3) Scroll to VLAN and then press .
4) Scroll to WAN Port and then press .
5) Set the VLAN Status, and enter the VID Number, Priority.
6) Press to save the change or to cancel.
7) Refer to the steps above to set the PC Port option.
To configure VLAN settings via Web user interface:
Click on Network->Advanced->VLAN to do the relating configuration. Contact your
system administrator for more information.
LLDP
The Link Layer Discovery Protocol (LLDP) is a vendor-neutral Layer 2 protocol that
allows a network device to advertise its identity and capabilities on the local network.
Enable LLDP function, the phone will go to switch to get related VLAN parameters
automatically (Synchronous with VLAN in switch).
To configure LLDP settings via web user interface:
1) Click on Network->Advanced.
