PAGE 15
Aquavar IPC Start-Up Genie
Xylem
Select Ramp Time
Fast: 5 sec accelerate, 3 sec decelerate.
Medium: 10 sec accelerate, 5 sec
decelerate.
Slow: 20 sec accelerate, 10 sec decelerate.
Select Yes to Autoset the rest of the settings.
For Simplex conguration, here are the
parameters that will get autoset:
AutosetConguration
Constant
Pressure
Transducer Max Feedback 300 [unit]
Transducer Type 4-20mA
Feedback 1 Source AI 53
PID Performance Normal
Sleep Mode Enabled
Sleep Frequency 30 Hz
Restart Difference 10 [unit]
No Water/Loss of Prime Fault Enabled
No Water/Loss of Prime Restart Time 10 min.
Select Setpoint 1
Setpoint 1
50.000psi
Ramp Time
Fast
Would you like to Autoset
the rest of the settings?
Yes
