Xylem hydrovar Instruction Manual

12
Section 5
TECHNICAL DATA
Hydrovar Power Supply
Rated Output Voltage Limits 48-62 HZ
Rated Current
Input
Recommended
Line Protection
Maximum
Wire Size
Cat #* HP V Amps Amps AWG
HVM1202 2
1 Ph, 220-240V -10%,
+15%
14 20 14
HVM1203 3 20 25 10
HVM3403 3
3 Ph, 380-460V
+-15%
7.6 10 14
HVM3405 5 11.4 15 14
HVM3407 7.5 15.1 20 12
HVM3410 10 19.6 20 10
HVM3415 15 27.8 30 8
* Listed catalog numbers are for master drives. Details also apply to corresponding basic and single units.
Hydrovar Output to the Motor
Rated Output Voltage Limits 48-62 HZ Rated Current Output Motor Connection Wires
Cat #* HP V Amps AWG
HVM1202 2
3 Ph, 240V
7 14
HVM1203 3 10 14
HVM3403 3
3 Ph, 480V
5.7 14
HVM3405 5 9 14
HVM3407 7.5 13.5 14
HVM3410 10 17 12
HVM3415 15 23 10

Xylem hydrovar Specifications

General

Frequency	50/60 Hz
Control type	Variable speed drive
Protection class	IP55
Communication protocols	Modbus
Relative Humidity	5% - 95% (non-condensing)
Altitude	Up to 1000 m without derating
Input voltage	200-690 V AC
Storage Temperature	-25°C to +70°C (-13°F to 158°F)
