ON - all Master Inverters in the system start (unless it is stopped manually or by a failure) before the rst
Basic Inverter runs.
For example: Address 1-3.......Master Inverters
Address 4-8……Basic Inverters
Switching order: Adr 1 Adr 2 Adr 3 Adr 4 Adr 5 Adr 6 Adr 7 Adr 8
Master Master Master Basic Basic Basic Basic Basic
OFF - One master (which controls the overall system) is running. With rising consumption all Basic Inverters
are turned on before other Masters run.
Switching order: Adr 1 Adr 4 Adr 5 Adr 6 Adr 7 Adr 8 Adr 2 Adr 3
Master Basic Basic Basic Basic Basic Master Master
0600
0600 SUBMENU
ERRORS
0605
0605 MIN. THRESH.
Minimum threshold limit
disabled
Possible settings: disabled - max. SENSOR RANGE
• An adjusted value >0.00 has to be reached within the programmed DELAY TIME [0610]
• If this value can’t be reached, the HYDROVAR stops with the failure message ”MIN. THRESHOLD ERROR”.
• To disable the minimum threshold limit, press
▼ till “disabled” is shown on the display.
0610
0610 DELAY - TIME
Minimum threshold limit delay time
2 Sec
Possible settings: 1 – 100 sec
Delay time to switch-off the HYDROVAR if the actual value drops below the minimum threshold limit or a
connected external low water protection at terminals X3/11-12 has been opened.
Notice: The minimum threshold function is also active during start up of the pump! Therefore the delay
time has to be set higher than the duration that is needed, to reach a value above the limit.
0615
0615 ERROR RESET
Automatic error reset
ON
Possible settings: ON – OFF
ON: Allows an automatic restart for 5 times in case of a failure. If the failure is still active after the 5th restart,
the HYDROVAR will shut off and the appropriate error message is shown.
The internal counter of the automatic error reset is decreased by 1 after each operating hour, so if an error
could be reset after 3 restarts, there are 3 further restarts possible after one hour, 4 after two hours and 5
automatic restarts after 3 operating hours. A manual reset can be done by switching an external ON/OFF
(X3/7-8) contactor.
PROGRAMMING

Xylem hydrovar Specifications

General

Frequency	50/60 Hz
Control type	Variable speed drive
Protection class	IP55
Communication protocols	Modbus
Relative Humidity	5% - 95% (non-condensing)
Altitude	Up to 1000 m without derating
Input voltage	200-690 V AC
Storage Temperature	-25°C to +70°C (-13°F to 158°F)
