44
60 60 SUBMENU SETTINGS
NOTE
Carefully read these instructions before changing the remaining parameters. Improper
settings can cause the drive to malfunction.
These parameters can be changed during operation. Therefore they should be changed only by trained
and qualied technicians. It is recommended to stop the HYDROVAR by pressing ▼ in the main menu
before changing parameters in submenues.
61
61 PASSWORD
enter password (0066 = Default) by pressing ▲ or ▼
0000
NOTICE! If the submenu is opened with the correct password it will remain open for a period of 10 min-
utes without entering the password again to access the secondary menu.
61 PASSWORD
Conrm by pressing and the rst window of the sub menu is shown
0066
62
62 JOG 0.0Hz
Both current output frequency and actual value are shown.
X.XX PSI
• By pressing ▲ or ▼ in this menu, the drive switches from control via external input (transducer) to manual
frequency control.
• Use the ▲ and ▼ buttons to change output frequency and pump speed to achieve the desired pressure
and ow.
• If this value becomes 0.00 Hz the HYDROVAR stops.
• Exit this menu by pressing or , and the HYDROVAR returns to the previously selected mode.
0100
0100 SUBMENU BASIC
SETTINGS
0105
0105 MODE
Select the operating mode
Controller
Possible settings: Controller, Cascade Relay, Cascade Serial, Cascade Synchron, Actuator
PROGRAMMING
