Xylem hydrovar - Programming Flow Chart

76
Section 12
0 MAIN MENU 20 SUBMENU
STATUS
0 MAIN MENU
XYLEM xx.x Hz 50 PSI
2 REQUIRED VAL 50 PSI
6 DATE xx-xx-20xx
22 SELECT DEVICE * 01 *
42 SEL. INVERTER * 01 *
27 2ND ERROR NO ERROR
28 3RD ERROR NO ERROR
29 4TH ERROR NO ERROR
30 5TH ERROR NO ERROR
21 STATUS UNITS 00000000
41 PROD. DATE xx-xx-xxxx 26 1ST ERROR NO ERROR
3 EFF REQ VAL 50 PSI 7 TIME xx:xx
23 STATUS DEVICE running 43 TEMP. INVERTER x: xx % xx Cº
4 START VALUE OFF
8 AUTO-START OFF
24 ENABLE DEVICE enabled
44 CURR. INVERTER x: xx %
46 OUTPUT FREQ x: xx.x Hz
5 LANGUAGE ENGLISH
9 OPERAT. TIME xxxxx:xx
25 MOTOR HOURS xxxxx:xx
45 VOLT. INVERTER x: xxx V
47 VER. INVERTER x: xx
20 SUBMENU
STATUS
40 SUBMENU
DIAGNOSTICS
40 SUBMENU
DIAGNOSTICS
PROGRAMMING FLOW CHART
