PROGRAMMING FLOW CHART
Section 12 (continued)
100 SUBMENU
BASIC SETTINGS
200 SUBMENU
CONF INVERTER
300 SUBMENU
REGULATION
400 SUBMENU
SENSOR
500 SUBMENU
SEQUENCE CNTR
100 SUBMENU
BASIC SETTINGS
60 SUBMENU
SETTINGS
200 SUBMENU
CONF INVERTER
300 SUBMENU
REGULATION
400 SUBMENU
SENSOR
500 SUBMENU
SEQUENCE CNTR
61 PASSWORD 0000 105 MODE Controller 202 SOFTWARE HV V01.3
205 MAX. UNITS 6
210 INVERTER ALL
215 RAMP 1 4 sec
225 RAMP 3 70 sec
260 FMIN TIME 0 sec
265 BOOST 5 %
310 WINDOW 10 % 510 ACT.VAL.DEC 2 PSI 540 DROP FREQ 42.0 Hz
410 CONF SENSOR Sensor 1
315 HYSTERESIS 80 % 515 ENABLE FREQ 48 Hz 545 OVERVALUE disabled
415 SENSOR TYPE
analog I 4-20mA
320 REG. MODE normal 520 ENABLE DLY 5 sec 550 OVERVAL DLY 0 sec
420 SENS. RANGE 300 PSI
325 FRQ. LIFT 30.0 Hz 525 SWITCH DLY 2 sec 555 SWITCH INTV 24 hours
425 SENS. CURVE linear
330 LIFT AMOUNT 0.0 % 530 DISABLE FRQ 30.0 Hz 560 SYNCH.LIM. 0.0 Hz
565 SYNCH.WIN. 2 Hz
570 MSTPRIORITY ON
430 SENS1 CAL 0 0 % = x,xx PSI
440 SENS2 CAL 0 0 % = x,xx PSI
435 SENS1 CAL X 0 % = xx,xx PSI
445 SENS2 CAL X 0 % = xx,xx PSI
285 SKIPFRQ CTR 0.0 Hz
270 KNEE FREQ. 60 Hz 286 SKIPFRQ RNG 60 Hz
275 POWER RED. OFF 290 CURR. LIMIT OFF
280 SEL.SW.FRQ. Auto 291 CURR. LIMIT 100 %
230 RAMP 4 70 sec
235 RAMP FMIN A 2 sec
240 RAMP FMIN D 2 sec
245 MAX. FREQ 60 Hz
250 MIN. FREQ 20 Hz
220 RAMP 2 4 sec
203 SET VER INV sel. 01 act. 01 106 PUMP ADDR 1
110 SET PASSW. 0066
115 LOCK FUNCT. 0066
120 DISP. CONTR. 75 %
125 DISP. BRIGHT 100 %
62 JOG Hz 50 PSI
305 JOG Hz 50 PSI 505 ACT.VAL.INC 5 PSI 535 DISABLE DLY 5 sec
405 DIMENS. UNIT PSI
255 CONF. FMIN F > 0
