Yale Assure Lock 2 Touch User Manual

11
P/N YRD450-KF-F Rev A
If you have confirmed that the existing holes are compatible with your new lock, please proceed to step 2 (skip step 1c).
If you need to make adjustments, go to
step 1c and find the closest match to each
aspect of your door on the Marking Template.
Tear off the Door Checker (pages 56) and follow the guidelines on both sides to
measure each aspect of your door and frame. There are some cases when existing
holes cannot be adjusted to be compatible.
Please do not drill any holes until you confirm that your door is compatible.
10 2 3 4 5 6
Door Checker Part 1
v
B A D
C E
10 2 3 4 5 6
Door Checker Part 2
H F G
1b
Check Door Measurements
If your door doesn’t have holes, please proceed to step 1c.

Yale Assure Lock 2 Touch Specifications

General

Keypad Type	Touchscreen
Power Source	4 AA Batteries
Backlit Keypad	Yes
Door Thickness	1-3/8" to 2-1/4"
Connectivity	Bluetooth
Compatibility	Amazon Alexa, Google Assistant, Apple HomeKit
Auto-Lock	Yes
Voice Assistance	Amazon Alexa, Google Assistant
Battery Life	Up to 1 year
Operating Temperature	-40°F to 140°F (-40°C to 60°C)
Remote Access	Yes
Guest Access	Yes
Security	BHMA Grade 2 Certified
Finish	Satin Nickel
