Yale Assure Lock 2 Touch

9
P/N YRD450-KF-F Rev A
Installation and Setup Guide
Required Tools
You Might Also Need
Failure to follow the Installation Guide precisely could result in damage to the product,
voiding the factory warranty, and could lead to failure of the product to provide access.
1. Phillips Head Screwdriver
2. Door Checker
(tear off pages 56 of this manual)
3. Tape Measure
4. Drill
5. Marking Template
(tear off pages 78 of this manual)
6. Pencil
7. Wood Mortise Chisel
8. Utility Knife
9. Level
10 2 3 4 5 6
Door Checker Part 1
