RX-V2500/DSP-AX2500
44
● V901 : 17-BT-23GNK (WD507500)
● PIN CONNECTION
● GRID ASSIGNMENT
Pin No.
Connection
Pin No. 65
F2
64
NX
63
NP
62
NP
61
P37
60
P36
59
P35
58
P34
57
P33
56
P32
55
P31
54
P30
53
P29
52
P28
51
P27
50
P26
49
P25
48
P24
47
P23
46
P22
45
P21
44
P20
43
P19
42
P18
41
P17
40
P16
39
P15
38
P14
37
P13
33
P9
32
P8
31
P7
30
P6
29
P5
28
P4
27
P3
26
P2
25
P1
24
NC
23
NC
22
NC
21
17G
20
16G
19
15G
18
14G
17
13G
16
12G
15
11G
14
10G
13
9G
12
8G
11
7G
10
6G
9
5G
8
4G
7
3G
6
2G
5
1G
4
NP
3
NP
36
P12
35
P11
34
P10
2
NX
1
F1
Connection
Note : 1) F1, F2 ..... Filament 2) NP ..... No pin 3) NC ..... No connection 4) NX ..... No extened Pin 5) 1G ~ 17G ..... Grid
(1G~14G) (15G)
(17G~15G)
(17G)
1-1
1-2
1-3
1-4
1-5
1-6
1-7
2-1
2-2
2-3
2-4
2-5
2-6
2-7
3-1
3-2
3-3
3-4
3-5
3-6
3-7
4-1
4-2
4-3
4-4
4-5
4-6
4-7
5-1
5-2
5-3
5-4
5-5
5-6
5-7
PATTERN AREA
2G 5G3G 4G 6G 7G 8G 9G 10G 11G 12G 13G1G 14G
16G17G 15G
y1
1d
1e
1f
1c
1b
2e 2c
s20
2f 2b 3f 3g 3b
2d
1g 2g
1a 2a 3a
3d
3e 3c
S3 S4 S5 S6 S7 S8 S9 S10 S11 S12 S13 S14
B1
S20S19
S16
S15
S1 S2
S17
S18 S18
B2
■ DISPLAY DATA
17G 16G 15G 14G~2G 1G
P1 S2 1-1 1-1
P2 S6 S14 2-1 2-1
P3 S7 3-1 3-1
P4 S3 S8 1a 4-1 4-1
P5 S1 S9 1b 5-1 5-1
P6 S4 S10 1c 1-2 1-2
P7 S5 S11 1d 2-2 2-2
P8 S12 1e 3-2 3-2
P9 S13 1f 4-2 4-2
P10 1g 5-2 5-2
P11 2a 1-3 1-3
P12 2b 2-3 2-3
P13 2c 3-3 3-3
P14 2d 4-3 4-3
P15 2e 5-3 5-3
P16 2f 1-4 1-4
P17 2g 2-4 2-4
P18 3a 3-4 3-4
P19 3b 4-4 4-4
P20 3c 5-4 5-4
P21 3d 1-5 1-5
P22 S15 3e 2-5 2-5
P23 S16 3f 3-5 3-5
P24 S17 3g 4-5 4-5
P25 S18 S20 5-5 5-5
P26 1-6 1-6
P27 2-6 2-6
P28 3-6 3-6
P29 4-6 4-6
P30 – 5-6 5-6
P31 – 1-7 1-7
P32 – 2-7 2-7
P33 – 3-7 3-7
P34 – 4-7 4-7
P35 –– 5-7 5-7
P36 ––B1 – S19
P37 ––B2 ––
● ANODE CONNECTION
