RX-V2500/DSP-AX2500
57
Ref. No. Location
D504 E5
Q542 E5
Q548 E5
• Semiconductor Location
■ PRINTED CIRCUIT BOARD (Foil side)
FUNCTION (3) P.C.B. (Side B) Lead Free Solder Used
