33
DTX-MULTI 12
[Check item]
Check the test result indicated on the LCD.
[Judgment indication]
In case of OK:
32:ROM (IC10)
OK
In case of NG:
32:ROM (IC10)
NG
[MIDI code output for judgment result]
OK: A0 20 02
NG: A0 20 03
[How to quit test]
Press the [+/INC] button to proceed to next test.
33. ROM (IC11)
[Test Code]
A0 21 00
[Initial indication]
33:ROM (IC11)
Press [ENTER]
[Test contents]
WAVE ROM (P2 ROM) data is read from the specifi ed address
and is compared with the prescribed value.
Judgment is OK if the value agrees with the specifi ed value.
(All the address terminals and all the data terminals of the
ROM are checked in this test.)
[Test method]
Press the [ENTER] button to execute the test.
[Check item]
Check the test result indicated on the LCD.
[Judgment indication]
In case of OK:
33:ROM (IC11)
OK
In case of NG:
33:ROM (IC11)
NG
[MIDI code output for judgment result]
OK: A0 21 02
NG: A0 21 03
[How to quit test]
Press the [+/INC] button to proceed to next test.
34. ROM (IC13)
[Test Code]
A0 22 00
[Initial indication]
34:ROM (IC13)
Press [ENTER]
[Test contents]
Executes ID Read test of the WAVE ROM (FLASH ROM).
Device ID is obtained from the ROM and is compared with the
specifi ed ID.
[Test method]
Press the [ENTER] button to execute the test.
[Check item]
Check the test result indicated on the LCD.
[Judgment indication]
In case of OK:
34:ROM (IC13)
OK
In case of NG:
34:ROM (IC13)
NG
[MIDI code output for judgment result]
OK: A0 22 02
NG: A0 22 03
[How to quit test]
Press the [+/INC] button to proceed to next test.
