Yamaha F60A - Page 35

69W3D1X
28
Symbol Unit
Model
F60AEHT
L1 mm (in) 584 (23.0)
L2 mm (in) 226 (8.9)
L3 mm (in) 755 (29.7)
L4 mm (in) 533 (21.0)
L5 (L) mm (in) 97 (3.8)
(X) mm (in) —
L6 (L) mm (in) 932 (36.7)
(X) mm (in) —
L7 mm (in) 417 (16.4)
L8 mm (in) 164 (6.5)
L9 (L) mm (in) 0 (0)
(X) mm (in) —
L10 mm (in) 62 (2.4)
H1 (L) mm (in) 870 (34.3)
(X) mm (in) —
H2 mm (in) 545 (21.5)
H3 mm (in) 175 (6.9)
H4 (L) mm (in) 527 (20.7)
(X) mm (in) —
H5 mm (in) 758 (29.8)
H6 (L) mm (in) 708 (27.9)
(X) mm (in) —
H7 mm (in) 354 (13.9)
H8 mm (in) 37 (1.5)
H9 mm (in) 759 (29.9)
H10 mm (in) 49 (1.9)
H11 (L) mm (in) 24 (0.9)
(X) mm (in) —
W1 mm (in) 192 (7.6)
W2 mm (in) 124 (4.9)
W3 mm (in) —
W4 mm (in) —
W5 mm (in) 360 (14.2)
W6 mm (in) 645 (25.4)
A1 Degree 40
A2 Degree 69
A3 Degree 4
T1 mm (in) —
Maintenance specifications
