Yamaha F60A - Power Trim and Tilt Unit

BRKT
Bracket unit
77
69W3D1X
Power trim and tilt unit
7
No. Part name Q’ty Remarks
1 Power trim and tilt unit 1
2 Plastic tie 3
Not reusable
3 PTT motor lead 2
4 Washer 2
5Bolt 2 M8
×
16 mm
6 Circlip 1
7 Shaft 1
8 Bushing 2
9Collar 1
10 Tilt pin 1
11 Collar 1
12 Collar 1
13 Shaft 1
