Yamaha F60A - Page 85

69W3D1X
78
No. Part name Q’ty Remarks
1Bolt 2 M5
×
8 mm
2 Relief valve bracket 1
3Bolt 3 M6
×
40 mm
4 Valve lock screw 1
5 Up-relief spring 1
6 Valve support pin 1
7 O-ring 1
Not reusable
8Ball 1
9 Down-relief spring 1
10 Valve support pin 1
11 Relief valve seal 1
12 Filter 1
13 O-ring 2
Not reusable
14 Spacer 2
15 Filter 2
16 O-ring 1
Not reusable
17 Manual valve 1
18 Circlip 1
Power trim and tilt unit
