Yamaha F60A - Page 86

BRKT
Bracket unit
79
69W3D1X
No. Part name Q’ty Remarks
1Bolt 2 M5
×
20 mm
2 Washer 2
3Bracket 1
4 O-ring 2
Not reusable
5 Spacer 2
6Spring 2
7 Valve pin 2
8Ball 2
9 Manual release spring 1
10 Ball 2
11 Gear pump cover 1
12 Spring 2
13 Shuttle piston 1
14 O-ring 1
Not reusable
15 Valve seal 2
16 Circlip 2
17 Pin 2
18 Drive gear 1
