Yamaha F60A - Swivel Bracket and Steering Arm

69W3D1X
76
Swivel bracket and steering arm
7
No. Part name Q’ty Remarks
1 Steering arm 1
2 Washer 1
3 Bushing 1
4 O-ring 2
Not reusable
5 Bushing 2
6 Swivel bracket 1
7 Bushing 2
8 Port tilt stop lever 1
9 Circlip 1
10 Steering yoke 1
11 Bushing 1
12 Bushing 2
13 Tilt stop lever joint 1
14 Spring holder 1
15 Bolt 1 M6
×
10 mm
16 Spring 1
17 Pin 2
Not reusable
18 Starboard tilt stop lever 1
Clamp brackets / Swivel bracket and steering arm
