7. Tighten the oil pan bolts
7
then exhaust
manifold bolts
8
, and then tighten them
to the specified torque.
8. Install the plate
9
and the muffler
0
to
the oil pan.
9. Install the muffler assembly
A
by insert-
ing the tip of the water pipe
4
into the
joint hole
a
of the upper case.
10. Tighten the upper case bolts
B
, and then
tighten them to the specified torque.
Installing the upper case
1. Install the upper mount
1
and bolts
2
into the upper case.
2. Install the lower mounts
3
and bolts
4
into the upper case.
3. Install the mount covers
5
.
T
R
.
.
Exhaust manifold bolt
8
:
10 N·m (1.0 kgf·m, 7.2 ft·lb)
S69W7100
LT
572
LT
572
T
R
.
.
Upper case bolt
B
:
21 N·m (2.1 kgf·m, 15 ft·lb)
Upper case
