Yamaha F60A - Page 80

BRKT
Bracket unit
73
69W3D1X
4. Install the upper and lower mounting
bolts into the swivel bracket
6
simulta-
neously.
5. Install the upper mounting nut
7
and
lower mounting nut
8
, and then tighten
them to the specified torque.
6. Install the cover
9
.
T
R
.
.
Upper mounting nut
7
:
24 N·m (2.4 kgf·m, 17 ft·lb)
Lower mounting nut
8
:
42 N·m (4.2 kgf·m, 30 ft·lb)
