Yamaha F60A - Page 61

69W3D1X
54
È
Tightening sequence
No. Part name Q’ty Remarks
1 Oil filter 1
2 Crankshaft 1
3 Bolt 10 M8
×
82 mm
4 Bolt 10 M6
×
35 mm
5 Crankcase 1
6 Oil seal 1
Not reusable
7 Main bearing 10
8 Oil seal 1
Not reusable
9 Connecting rod bearing 8
10 Connecting rod cap 4
11 Bolt 8
12 Dowel pin 2
13 Cylinder block 1
14 Connecting rod 4
15 Piston pin clip 8
Not reusable
16 Piston pin 4
17 Piston 4
18 Oil ring 4
19 Second ring 4
20 Top ring 4
21 Gasket 1
Not reusable
22 Exhaust cover 1
23 Thermostat 1
24 Gasket 1
Not reusable
25 Cover 1
26 Clamp 2
27 Grommet 1
28 Anode 1
29 Cover 1
30 Cover 1
31 Bolt 1 M6
×
20 mm
32 Bolt 1 M5
×
12 mm
33 Bolt 12 M6
×
35 mm
Power unit
