Yamaha F60A - Page 65

69W3D1X
58
No. Part name Q’ty Remarks
1 Drive shaft 1
2 Oil seal 1
Not reusable
3 Oil seal housing 1
4 O-ring 1
Not reusable
5 Circlip 1
6 Shift rod 1
7 O-ring 1
Not reusable
8 Taper roller bearing 1
Not reusable
9 Bearing outer race 1
Not reusable
10 Pinion shim — As required
11 Sleeve 1
12 Washer 1
13 Oil seal housing 1
14 O-ring 1
Not reusable
15 Oil seal 2
Not reusable
16 Seal 1
17 Plate 1
18 Hose 1
19 Plastic tie 1
Not reusable
20 Joint 1
21 Nut 1
22 Water inlet cover 2
23 Screw 1
24 Shift cam 1
25 Needle bearing 1
26 Pinion 1
27 Nut 1
28 Forward gear shim — As required
29 Bearing outer race 1
Not reusable
30 Taper roller bearing 1
Not reusable
31 Forward gear 1
32 Lower case 1
33 Cover 1
34 Gasket 1
Not reusable
35 Check screw 1
36 Gasket 1
Not reusable
37 Drain screw 1
Drive shaft and lower case
1
2
3
4
5
6
7
8
9
