Yamaha F60A - Page 73

69W3D1X
66
No. Part name Q’ty Remarks
1 Bottom cowling 1
2 Rubber seal 1
3 Washer 1
4 Bushing 2
5 Shift rod bracket 1
6Bolt 1
7Spring 1
8Ball 1
9 Shift rod 1
10 Flushing device 1 Flushing device model
11 Bracket 1 Flushing device model
12 Bolt 1 M6
×
16 mm / Flushing device model
13 Screw 2 ø6
×
20 mm / Flushing device model
14 Flushing hose 1 Flushing device model
15 Bolt 4 M6
×
30 mm
16 Grommet 4
17 Collar 4
18 Grommet 1
19 PTT motor lead 1
20 Trim sensor coupler 1
21 Screw 1 ø6
×
25 mm
22 Bolt 2 M6
×
20 mm
23 Bracket 1
24 Power trim and tilt switch 1
25 Warning indicator 1 Tiller handle model
26 Screw 1 ø6
×
14 mm / Tiller handle model
27 Pilot water hose 1
28 Collar 2
29 Grommet 2
30 Cowling lock lever 1
31 Washer 1
32 Wave washer 1
33 Bushing 2
34 Lever 1
35 Bolt 1 M6
×
12 mm
36 Spring 1
37 Hook 1
38 Bolt 1 M6
×
20 mm
Bottom cowling
