Yamaha F60A - Page 75

69W3D1X
68
No. Part name Q’ty Remarks
1 Muffler assembly 1
2 Upper case 1
3 Muffler seal 1
4 Rubber seal 1
5 Dowel pin 2
6Grommet 1
7Damper 1
8Screw 2 ø5
×
16 mm
9 Baffle plate 1
10 Bolt 4 M8
×
30 mm
11 Drive shaft bushing 1
12 Circlip 1
13 Ground lead 1
14 Screw 1 ø6
×
8 mm
15 Cap 2
16 Bolt 2 M12
×
170 mm
17 Washer 2
18 Rubber washer 2
19 Washer 2
20 Lower mount 2
21 Washer 2
22 Mount cover 2
23 Bolt 4 M8
×
30 mm
24 Bolt 2 M8
×
175 mm
25 Plate 1
26 Bolt 3 M8
×
30 mm
27 Upper mount 1
28 Nut 2
29 Grease nipple 1
30 Washer 2
31 Nut 2
32 Cover 1
33 Bolt 2 M8
×
20 mm
Upper case
