Yamaha F60A - Power Trim and Tilt Unit Service

69W3D1X
70
No. Part name Q’ty Remarks
1 Oil seal 1
Not reusable
2 Exhaust guide 1
3Grommet 1
4 Anode 1
5 Cover 1
6Bolt 1 M6
×
20 mm
7 Cover 1
8Bolt 1
9 Gasket 1
Not reusable
10 Gasket 1
Not reusable
11 Relief valve housing 1
12 Relief valve 1
13 Spring 1
14 Cotter pin 1
Not reusable
15 Bolt 2 M6
×
25 mm
16 Bolt 2 M6
×
16 mm
17 Oil strainer 1
18 Bolt 1 M6
×
25 mm
19 Gasket 1
Not reusable
20 Pipe 1
21 Rubber seal 1
22 Dowel pin 2
23 Bolt 10 M6
×
25 mm
24 Drain bolt 1
25 O-ring 1
Not reusable
26 Oil pan 1
27 Gasket 1
Not reusable
28 Exhaust manifold 1
29 Bracket 1
30 Washer 3
31 Bolt 3 M6
×
50 mm
32 Gasket 1
Not reusable
33 Gasket 2
Not reusable
34 Plate 1
35 Muffler 1
36 Bolt 6 M6
×
25 mm
Upper case
