Yamaha F60A - Page 88

BRKT
Bracket unit
81
69W3D1X
No. Part name Q’ty Remarks
1Screw 3 ø5
×
20 mm
2Yoke 1
3 O-ring 1
Not reusable
4 Armature 1
5 Washer 1
6 Bushing 1
7Screw 2 ø4
×
12 mm
8 Lead 1
9Brush 2 1
10 Brush 1 1
11 Brush holder 1
12 Circuit breaker 1
13 Brush spring 2
14 PTT motor base 1
15 Oil seal 1
Not reusable
