3-2
Outboard Rigging Guide - 2001 Wire Harnesses
F25T 2-Stroke
F80/100 115~
F15 40T F115 C40T 250 L130
REF. F9.9 9.9 25 To FT50 To V4 To
NO. DESCRIPTION PART NUMBER
T8 T9.9 15 30 F25E 90 F40T C115 V6 L250
Control Box Adapters
16 Aftermarket Harness 704-85721-00-00 O O O O O O
To 704/705 Box
17 Aftermarket Control 704-82541-10-00 O O O O O O
To Main Harness
Instrument Panel
18 Gauge (One Fuse) 6Y5-83553-00-00 O 1 1+ 1 1
19 Gauge (Two Fuses) 6Y5-83553-M0-00 O 2 2+ 2 2 2
20-1 Trim & Oil Gauge Lead 5m * 64D-82553-50-00 O O O O
20-2 Trim & Oil Gauge Lead 7m * 64D-82553-70-00 1 1+ 1 1 1
20-3 Trim & Oil Gauge Lead 8m * 64D-82553-80-00 2 2+ 2 2 2
20-4 Trim & Oil Gauge Lead 9.5m * 64D-82553-90-00 O O O Sk
Extensions
21-1 Trim Gauge Lead 3m 6R3-82553-30-00 O O O O
21-2 Trim Gauge Lead 5m 6R3-82553-50-00 O O O O
21-3 Trim Gauge Lead 7m 6R3-82553-70-00 O O O O
21-4 Trim Gauge Lead 8m 6R3-82553-80-00 O O O O
21-5 Trim Gauge Lead 9.5m 6R3-82553-90-00 O O O O
22-1 Oil Gauge Lead 5m 6R3-82521-50-00 O O O
22-2 Oil Gauge Lead 7m 6R3-82521-70-00 O O O
22-3 Oil Gauge Lead 8m 6R3-82521-80-00 O O O
22-4 Oil Gauge Lead 9.5m 6R3-82521-90-00 O O O
23 PT & T Switch Lead
Extension 2m 6H5-82553-00-00 O
Fuel Management
24-1 F.M. Meter to Sender** 5m 6Y5-83553-F0-00 O Ss
24-2 F.M. Meter to Sender ** 8m 6Y5-83553-F1-00 O Ss
25 Sender Extension 3m 6X1-82531-00-00 O O
26 F.M. Meter to Tach. 703-82531-00-00 Ss
WIRE HARNESSES (Cont’d.)
* The combined 64D Trim & Oil Lead uses the same connectors as the separate 6R3 Oil Gauge Lead and the 6R3 Trim Gauge
Leads. The 64D Harness and the 6R3 Harnesses are fully interchangeable as a set. That is one 6R3 Oil Gauge Harness and
one 6R3 Trim Gauge Harness of the same length can be used to replace a 64D Trim & Oil Lead of the same length. In addi-
tion, the 6R3 Harnesses can be used as extensions with a 64D Harness.
** F.M. Meter to Sender Harness included with fuel management kit is -F1 8m long. For replacement -F0 5m must be used
with extensions.
Sc = Standard in Crate * = Not 225X/250 1 = Single Gauge Kit
Sk = Standard in Standard Rigging Kit Or = Optional Recommended 2 = Dual Gauge Kit
if ordered with engine. O = Optional
Ss = Standard, Shipped Separate + = Except F25T
D =With Oil Tank
