3-18
Outboard Rigging Guide - 2001 Switch Panels
30 mm
(1.17 in )
7.7 mm (.31 in)
7.7 mm (.31 in)
19 mm
(.75 in)
56 mm
(2.2 in)
41 mm
(1.58 in)
68 mm (2.67 in)
52 mm (2.06 in)
13.7 mm
(.82 in)
14.3 mm
(.56 in)
4x 5.1 mm (.2 in)
Oil Lamp
DRILL TEMPLATE (Actual Size)
