3-25
Outboard Rigging Guide - 2001 Battery Installations
Battery Isolator Wiring
For model year 2001, Yamaha has changed the
battery isolator leads. The 3.1L Salt Water Series
225/250hp, carburetor 150/V150 and all HPDI
engines will remain the same.
The OX66 V-Max 200/225/250hp and OX66 2.6L
engines have received a change as pointed out
below.
OX66 V-Max 200/225/250hp will come with a
new battery cable. The battery cable length has
also been changed.
BATTERY ISOLATOR LEADS
2000 2001
Length 13.3 ft 11.0 ft
Number of Wires 3 2
Isolator Lead Required Not Required Requires Part # 68F-81949-00-00
Type of Installation Refer To
1 Motor 2 Batteries & No Battery Switch Page 3-26
2 Motors 3 Batteries & No Battery Switch Page 3-26
1 Motor 2 Batteries & On/Off Battery Switch Page 3-27
2 Motors 3 Batteries & On/Off Battery Switch Page 3-28
2 Motors 3 Batteries & 1/Both/2 Battery Switch Page 3-29
Bass Boat 12/24 Volt Trolling Motor (3 pin plug) Page 3-30
Bass Boat 12/24 Volt Trolling Motor (4 pin plug) Page 3-31
Bass Boat 24 Volt ONLY Trolling Motor Page 3-32
The battery isolator cannot be used on a 24/36 volt trolling motor system. Ashort could result caus-
ing a fire. Consult the trolling manufacturer for wiring recommendations.
