6-32
Outboard Rigging Guide - 2001 F40 4-Cyl., F/T50 Tiller Handle Kit
F40 4-Cyl., F/T50 Tiller Handle Kit [Cont’d.]
REF
NO PART NUMBER DESCRIPTION QTY.
61 93430-04M03-00 • Circlip 2
62 63D-42131-10-00 • Cover, Handle Steering 1
63 90480-14M14-00 • Grommet 1
64 97885-06016-00 • Screw, Pan Head 4
65 92990-06600-00 • Washer, Plate 4
66 97885-06040-00 • Screw, Pan Head 3
67 92990-06600-00 • Washer, Plate 3
68 6H3-82540-00-00 • Neutral Switch Ass’y1
69 62Y-82554-00-00 • Stay, Neutral Switch 1
70 62Y-82555-00-00 • Damper, Main Switch 1 1
71 97395-06014-00 • Bolt 2
72 92990-06600-00 • Washer, Plate 2
73 6H2-82586-01-00 • Extension, Wire Harness 1
74 6H5-82510-00-00 • Main Switch Ass’y1
75 63D-82575-00-00 • Engine Stop Switch Ass’y1
76 682-82556-00-00 • Stopper 1
77 689-8257Y-00-00 • Cap 1
78 97095-06025-00 • Bolt 1
79 92995-06100-00 • Washer, Spring 1
80 63D-8252F-00-4D • Cover, Main Switch 1
81 63D-8252E-00-4D • Cover, Main Switch 1
82 97885-06025-00 • Screw, Pan Head 1
83 92995-06100-00 • Washer, Spring 1
84 97095-06020-00 • Bolt 1
85 92995-06100-00 • Washer, Spring 1
86 97885-06012-00 • Screw, Pan Head 1
87 90465-13M36-00 • Clamp 1
88 630-82563-00-00 • Trim & Tilt Switch 1
89 97805-06016-00 • Screw, Pan Head 1
90 92995-06600-00 • Washer, Plain 1
91 63D-42508-00-00 Steering Friction Ass’y1
92 63D-42527-00-00 • Plate, Friction 1
93 63D-42546-00-00 • Nut 2
94 63D-42541-00-00 • Damper 2
95 90201-08M01-00 • Washer, Plate 2
96 97095-08050-00 • Bolt 2
97 92990-08600-00 • Washer, Plate 2
98 63D-42526-00-00 • Plate, Friction 1
99 63D-4252800-00 • Plate, Friction 2
100 63D-42562-00 • Shaft, Steering Lock 1
101 90185-10M01-00 • Nut, Self-locking 1
102 63D-42561-00-00 • Knob, Steering Lock 1
103 682-43318-01-00 • Cover 1
104 97095-06016-00 Bolt 2
105 92995-06100-00 Washer, Spring 2
106 62Y-82361-00-00 Clamp, Cord 1
107 90161-06M03-00 Screw, Tapping 1
108 97095-06035-00 Bolt 1
109 92990-06600-00 Washer, Plate 1
110 90387-06M26-00 Collar 1
111 90464-15M11-00 • Zip Tie 1
112 688-83383-11-00 • Buzzer 1
113 6H4-83386-00-00 • Buzzer Stay 1
114 97013-05010-00 • Bolt 2
115 90990-05100-00 • Spring Washer 2
116 90185-10051-00 • Nut 2
REF
NO PART NUMBER DESCRIPTION QTY.
1 62Y-W0086-20-4D Handle Steering Ass’y1
2 63D-42121-00-4D • Bracket 1
3 63D-42111-00-4D • Handle, Steering 1
4 6H2-42137-00-00 • Indicator, Throttle 1
5 90269-02M09-00 • Rivet 1
6 63D-44100-10-00 • Shift Link Ass’y1
7 63D-44104-00-00 • Plate Comp. 1
8 63D-48261-00-00 • Arm, Throttle 1
9 63D-42115-00-00 • Shaft, Steering Handle 1
10 650-42152-00-94 • Gear 1
11 91690-30025-00 • Pin, Spring 1
12 63D-42159-00-00 • Stay 1
13 98580-06016-00 • Screw, Pan Head 2
14 99001-08600-00 • Circlip 1
15 63D-44113-00-00 • Cam Plate, Handle 1
16 63D-48236-00-00 • Roller, Detent 1
17 63D-48119-00-00 • Cover 1
18 63D-42153-00-00 • Shaft, Throttle Control 1
19 63D-44132-00-00 • Bushing 1
20 63D-48118-00-00 • Clip, Shift Lever 1
21 63D-48237-00-00 • Adaptor 1
22 98780-05014-00 • Screw, Flat Head 2
23 63D-48238-00-00 • Spring, Detent 1
24 63D-42181-00-00 • Washer 2
25 63D-44114-00-00 • Stopper 1
26 97095-06016-00 • Bolt 4
27 92990-06600-00 • Washer, Plate 4
28 63D-42725-00-00 • Grommet 1
29 62Y-48321-00-00 • Cable 1
30 62Y-26301-00-00 • Throttle Cable Ass’y1
31 90101-12M09-00 • Bolt 1
32 92990-12200-00 • Washer, Plain 1
33 63D-48531-00-00 • Bracket, Remote Control 1
34 63D-48538-00-00 • Clamp, Cable 1 2
35 90464-09M42-00 • Clamp 1
36 97095-06016-00 • Bolt 2
37 92990-06600-00 • Washer, Plate 2
38 90386-12M93-00 • Bush 2
39 90386-29M95-00 • Bush 1
40 92990-12600-00 • Washer, Plate 1
41 90206-12M21-00 • Washer, Wave 1
42 90185-12058-00 • Nut, Self-locking 1
43 90387-12M02-00 • Collar 1
44 63D-42126-00-00 • Friction, Steer Hndl Grip 1
45 63D-48154-00-00 • Knob, Throttle 1
46 95380-06600-00 • Nut 1
47 91490-20015-00 • Pin, Cotter 1
48 6G8-44191-00-00 • Indicator, Shift 1
49 90202-24M53-00 • Washer, Plate 1
50 97395-08040-00 • Bolt (97095-08040-00) 1
51 92990-08600-00 • Washer, plate 1
52 63D-44159-00-00 • Handle, Gear Shift 1
53 90159-06M18-00 • Screw, with Washer 2
54 63D-44173-00-00 • Lever, Shift Control 1
55 664-42119-00-00 • Grip, Steering Handle 1
56 6G1-42177-00-00 • Rubber, Handle 1
57 90149-05M13-00 • Screw 1
58 92990-10600-00 • Washer, Plate 1
59 90501-23215-00 • Spring, Compression 1
60 90386-08032-00 • Bush 1
• Component parts
To Next Page
