7-25
Outboard Rigging Guide - 2001 25HP Remote Control Attach. Kit
11. Screw in the cable joint (over the remote con-
trol cable) a minimum of 8mm (0.31 in).
Align joint hole with the cable joint set pin,
and lock it with the lock nut. Lock the cable
joint to the cable joint set pin with this lock
plate.
I f the cable is not screwed in at least 8mm, the
cable joint could break. T his could cause loss of
control and an accident.
12. Fit the new cover.
Additional Parts Required
To Next Page
