8-2
Outboard Rigging Guide - 2001 Propellers
Location of Letter Codes & Pitches
The location of the letter code and pitch on the
propeller varies. To find this information on alu-
minum and stainless steel propellers, use the illus-
tration and the corresponding table below. The
circles numbered in the illustration indicate the
location of the letter code and corresponds with
the far left column in the table.
Location of Letter Codes on Aluminum and Some Selected Stainless Steel Propellers (1994~)
T25
F30 C60~C90
F40(3) T50~130
F4 F8 T8 9.9/F15 F25 C40/55 F80/100 225X DX150 L150/ L225
HP 2 3 4/5 6/8 T9.9 F9.9/15 25/30 40/50 115 V6 250 L130 D150 L200 L250
Type A BS BA N R J F G K M T KL MF/MR ML TL
Mat'l AL AL AL AL AL AL AL SST AL SST AL SST AL SST
1XXXXX X X X SST
2 X X X X X X X X X
3 X X X X X X X X X X X X
4X SST X SST
