Yamaha F80 - Page 49

1-12
Outboard Rigging Guide - 2001 2001 Model
Outboard Motor Crate Contents
F9.9ELRZ
Part Number Description Qty
LIT-18626-04-26 Owner's Manual 1
90580-50M01-00 Emergency Starter Ass'y 1
6Y1-24306-51-00 Fuel Pipe Complete 1
91490-30025-00 Split Pin 2
6G8-48532-50-00 Remote Control Brckt 2 1
6G8-48538-50-00 Cable Clamp 1 1
97595-06530-00 Bolt 1
97595-06512-00 Bolt 1
6G8-48565-50-00 Grommet 1
6G8-48511-20-00 Steering Hook 1
97595-06516-00 Bolt W/Washer 2
6G8-26364-00-00 Throttle Cable End 2 2
6G8-26363-00-00 Throttle Cable End 1 2
6G8-82541-00-00 Wire Lead 1
6G8-83530-00-00 Pilot Lamp Ass'y 1
6E5-43145-01-00 Clamp Bracket Cap 1
90185-09M01-00 Nylon Lock Nut 2
90201-10M20-00 Plate Washer 2
93210-16275-00 O-Ring 1
6G8-61351-00-00 Steering Link Rod 1
90170-09M03-00 Nut 2
90201-10M63-00 Plate Washer 1
6E5-61355-00-00 Bolt 1
90387-10M06-00 Collar 1
6G8-61348-00-00 Plate 1
90185-08057-00 Nylon Lock Nut 2
97575-08525-00 Bolt 2
T9.9ELHZ, EXHZ
Part Number Description Qty
LIT-18626-04-26 Owner's Manual 1
90580-50M01-00 Emergency Starter Ass'y 1
91490-30025-00 Split Pin 2
6G8-43319-03-00 Plate 1
90101-08M88-00 Bolt 1
92995-08600-00 Plate Washer 8
90201-08MA4-00 Plate Washer 8
90185-08057-00 Nylon Lock Nut 14
6Y1-24306-51-00 Fuel Pipe Complete 1
T9.9ELRZ/EXRZ
Part Number Description Qty
LIT-18626-04-26 Owner's Manual 1
90580-50M01-00 Emergency Starter Ass’y1
6Y1-24306-51-00 Fuel Pipe Complete 1
91490-30025-00 Split Pin 2
6G8-48532-50-00 Remote Control Bracket 2 1
6G8-48538-50-00 Cable Clamp 1 1
97595-06530-00 Bolt 1
97595-06512-00 Bolt 2
6G8-48565-50-00 Grommet 1
6G8-48511-20-00 Steering Hook 1
97595-06516-00 Bolt 2
6G8-61348-00-00 Plate 1
90101-08M88-00 Bolt 2
92995-08600-00 Washer 2
90185-08057-00 Nylon Lock Nut 2
6G8-26364-00-00 Throttle Cable End 2 2
6G8-26363-00-00 Throttle Cable End 1 2
6G8-82541-00-00 Wire Lead 1
6G8-83530-00-00 Pilot Lamp Ass'y 1
6E5-43145-01-00 Clamp Bracket Cap 1
6G8-61351-00-00 Steering Link Rod 1
90170-09M03-00 Nut 2
90201-10M63-00 Plate Washer 1
6E5-61355-00-00 Bolt 1
90387-10M06-00 Collar 1
90185-09M01-00 Nylon Lock Nut 2
90201-10M20-00 Plate Washer 2
93210-16275-00 O-Ring 1
90201-08MA4-00 Plate Washer 1
97575-08525-00 Bolt 2
F15MSHZ/MLHZ, F15ESHZ/ELHZ
Part Number Description Qty
LIT-18626-04-27 Owner's Manual 1
90580-50M01-00 Emergency Starter Ass'y 1
6Y1-24306-51-00 Fuel Pipe Complete 1
F15PLHZ
Part Number Description Qty
LIT-18626-04-27 Owner's Manual 1
6G8-15780-00-00 Emergency Starter Ass'y 1
6Y1-24306-53-00 Fuel Pipe Complete 1
663-48344-00-00 Cable End (Remote Control) 2
90468-18008-00 Clip 2
