Outboard Rigging Guide - 2001 2001 Model
Outboard Motor Crate Contents
115TLRZ/TXRZ, 130TLRZ/TXRZ
Part Number Description Qty
LIT-18626-04-16 Owner's Manual 1
6G5-2818N-31-00 Caution Tag 1
61A-28107-15-00 Rigging Instructions 1
90580-50M01-00 Emergency Starter Ass'y 1
6E5-43145-01-00 Clamp Bracket Cap 1
6E5-61351-01-00 Steering Link Rod 1
6E5-61355-00-00 Bolt 1
90201-12M05-00 Bolt 4
90185-09M01-00 Nylon Lock Nut 2
90201-10M20-00 Plate Washer 2
90201-12M05-00 Plate Washer 4
90201-13M01-00 Plate Washer 8
90387-10M61-00 Collar 1
90560-12M01-00 Spacer 1
93210-16275-00 O-Ring 1
95380-12600-00 Nut 8
L130TXRZ
Part Number Description Qty
LIT-18626-04-16 Owner's Manual 1
6G5-2818N-31-00 Caution Tag 1
61A-28107-15-00 Rigging Instructions 1
90580-50M01-00 Emergency Starter Ass'y 1
90201-12M05-00 Bolt 4
90101-12M77-00 Bolt 2
90201-12M05-00 Plate Washer 4
90201-13M01-00 Plate Washer 8
95380-12600-00 Nut 8
ABA-DUALT-IE-BR Tie Bar 1
150TXRZ
Part Number Description Qty
LIT-18626-04-16 Owner's Manual 1
6G5-2818N-31-00 Caution Tag 1
61A-28107-15-00 Rigging Instructions 1
90580-50M01-00 Emergency Starter Ass'y 1
6E5-43145-01-00 Clamp Bracket Cap 1
6E5-61351-01-00 Steering Link Rod 1
6E5-61355-00-00 Bolt 1
64D-82105-00-00 Battery Cable 1
90201-12M05-00 Bolt 4
90101-12M77-00 Bolt 2
90185-09M01-00 Nylon Lock Nut 2
90201-10M20-00 Plate Washer 2
90201-12M05-00 Plate Washer 4
90201-13M01-00 Plate Washer 8
90387-10M61-00 Collar 1
90560-12M01-00 Spacer 1
92990-06100-00 Spring Washer 1
92990-08100-00 Spring Washer 1
93210-16275-00 O-Ring 1
95380-12600-00 Nut 1
95380-08700-00 Nut 1
95380-12600-00 Nut 8
