Yamaha F80 - Page 68

2-5
Outboard Rigging Guide - 2001 Engine Mounting Dimensions
Transom Dimensions
MODEL J K L M N O P Q R
2 614mm 302mm 397mm 331mm 276mm 122mm 164mm 100mm
24.2in 11.9in 15.6in 13.0in 10.9in 4.8in 6.5in 3.9in
3 S:654mm (25.7in) 343mm 419mm 317mm 311mm 107mm 223mm 103mm
13.7in 16.5in 12.5in 12.2in 4.2in 8.8in 4.1in
F4 S:643.0mm (25.3in) 386mm 511mm 342mm 375mm 141.3mm 259mm 104mm
L:770.0 (30.3in) 15.2in 20.1in 13.5in 14.8in 5.6in 10.2in 4.1in
5 S:653mm (25.7in) 358mm 459mm 333mm 344mm 145mm 252mm 105mm
14.1in 18.1in 13.1in 13.5in 5.7in 9.9in 4.1in
F6/8 S:681.5mm (26.8in) 317mm 528mm 601mm 430mm 121.5mm 355mm 123mm
L:808.5mm (31.8in) 12.5in 20.8in 23.7in 16.9in 4.8in 13.9in 4.8in
T8P L:868mm (34.2in) 317mm 528mm 601mm 430mm 121.5mm 366mm 157mm
X:936mm (36.8in) 12.5in 20.8in 23.7in 16.9in 4.8in 14.4in 6.2in
8 S:682mm (26.9in) 295mm 470mm 439mm 363mm 114mm 359mm 123mm
11.6in 18.5in 16.9in 14.3in 4.5in 14.1in 4.8in
9.9/15 S:705mm (27.8in) 335mm 526mm 479mm 393mm 180mm 355mm 135mm
13.2in 20.7in 18.9in 15.5in 7.1in 14.0in 5.3in
F9.9 S:679mm (26.7in) 293mm 556mm 440mm 439mm 152mm 356mm 135mm
L:824mm (32.4in) 11.5in 21.9in 17.3in 17.3in 6.0in 14.0in 5.3in
T9.9 L:871mm (34.3in) 293mm 556mm 571mm 439mm 152mm 356mm 157mm
X:947mm (37.3in) 11.5in 21.9in 22.5in 17.2in 2.4in 14.0in 6.2in
F15 S:706mm (27.8in) 375mm 589mm 528mm 475mm 168mm 356mm 135mm
L:833mm (32.8in) 14.8in 23.2in 20.8in 18.7in 6.69in 14.0in 5.3in
F15P L:834.6mm (32.9in) 372.2mm 586.5mm 517.4mm 483mm 159.8mm 363.7mm 135mm
14.7in 23.1in 20.4in 19.0in 6.3in 14.3in 5.3in
F25T 834mm 441mm 698mm 523mm 580mm 190mm 432mm 144mm 114mm
T25T 32.8in 17.4in 27.5in 17.0in 22.8in 7.5in 17.0in 5.7in 15.8in
F25E S:707mm (27.8in) 441mm 698mm 523mm 580mm 190mm 432mm 144mm 114mm
F25M L:834mm (32.8in) 17.4in 27.5in 17.0in 22.8in 7.5in 17.0in 5.7in 15.8in
25 2 CYL S:703mm (27.7in) 365mm 584mm 508mm 428mm 185mm 402mm 44mm
L:830mm (32.7in) 14.4in 23.0in 20.0in 16.9in 7.3in 15.8in 5.7in
25/3 S:712mm (28.0in) M:446mm (17.6in) M:657mm (25.9in) 497mm 465mm M:198mm (7.8in) 496mm 148mm 570mm
30 L:833mm (32.8in) E:428mm (16.9in) E:647mm (25.5in) 19.6 18.3in E:114mm (4.5in) 19.5in 5.8in 22.4in
40M/T S:751mm (29.6in) M:472mm (18.6in) M:683mm (26.9in) M:490mm(19.3in) M:493mm (19.4in) 175mm 600mm
C40T L:878mm (34.6in) T:439mm (17.3in) T:688mm (27.1in) T:527mm (20.7in) T:529mm (20.8in) 6.9in 23.6in
F30T/3 S:753.1mm (29.7in) 464mm 708mm 763mm 569mm 132mm 521mm 175mm 600mm
F40/E/T/3 L:876mm (34.5in) 18.3in 27.9in 30.1in 22.4in 5.2in 20.5in 6.9in 23.6in
F40/M/3 L:876mm (34.5in) 493mm 727mm 763mm 569mm 175mm 521mm 175mm 600mm
19.4in 28.6in 30.1in 22.4in 6.9in 20.5in 6.9in 23.6in
50, C50 L:878mm (34.6in) T:439mm (17.3in) T:688mm (27.1in) 789mm T:528mm (20.8in) T:142 (5.6in) T:529mm (20.8in) 125mm 600mm
31.1in 6.9in 23.6in
F50/T50 F:876mm(34.5in) 521mm 734mm 753mm 576mm 223mm F:532mm (21.0in) F:175mm 600mm
T:914mm (35.9in) 20.5in 28.9in 29.7in 22.7in 8.8in T:562mm (22.1in) 6.9in 23.6in
T:190mm
7.5in
60/70 901mm 472mm 719mm (28.3in) 651mm 547mm (21.5in) 151mm (5.9in) 562mm (22.1in) 191mm 600mm
C60/C70 35.4in 18.6in 28.3in 27.8in 7.5in 23.6in
F80/F100 L:917mm (36.1in) 666mm 856mm 793mm 651mm 171mm 574mm 191mm 660mm
X:1044mm (41.1in) 26.2in 33.7in 31.2in 25.6in 6.7in 22.6in 7.5in 26.0in
90/C90 901mm 512mm 730mm 545mm 180mm 547mm 191mm 600mm
35.5in 20.2in 28.7in 21.5in 7.1in 21.5in 7.5in 23.6in
F/LF115 L:929mm (36.6in) 681mm 879mm 860mm 662mm 115mm 631mm 191mm 660mm
X:1056mmd (41.6in) 26.8in 34.6in 33.9in 26.1in 4.5in 24.9in 7.5in 26.0in
115/130 L:929mm (36.6in) 543mm 737mm 554mm 177mm 631mm 191mm 660mm
X:1056mm (41.6in) 21.4in 29.0in 21.8in 7.0in 24.9in 7.5in 26.0in
150 L:946mm (37.2in) 670mm 791mm 550mm 179mm 647mm 210mm 660mm
SX150~200 X:1072mm (42.2in) 26.4in 31.2in 21.7in 7.0in 25.5in 8.3in 26.0in
LX150~200
V150 946mm 691mm 864mm 557mm 179mm 647mm 210mm 660mm
VX150 37.2in 27.2in 34.0in 21.9in 7.0in 25.5in 8.3in 26.0in
DX150 882mm 691mm 864mm 557mm 179mm 717mm 210mm 660mm
34.7in 27.2in 34.0in 21.9in 7.0in 28.2in 8.3in 26.0in
VZ150/175 947mm 960mm 180mm 646mm 210mm 660mm
200 37.3in 37.8in 7.1in 25.5in 8.3in 26.0in
Z150~200 L:947mm (37.3in) 708mm 835mm 613mm 180mm 646mm 210mm 660mm
LZ150~200 X:1074mm (42.3in) 27.9in 32.9in 24.2in 7.1in 25.5in 8.3in 26.0in
VX200/225 950mm 735mm 923mm 591mm 179mm 685mm 216mm 660mm
250/3.1L 37.4in 28.9in 36.3in 23.3in 7.0in 27.0in 8.5in 26.0in
SX225/250 X:1077mm (42.4in) 710mm 818mm 566mm 181mm 673mm 216mm 660mm
LX225/250 U:1203mm (47.4in) 28.0in 32.2in 22.3in 7.1in 26.5in 8.5in 26.0in
